SPECIFICATION :

Frame
Scale Carbon, IMP3, HMX NET, Tapered HT, PM 160 Disc, Carbon dropout, PFBB30, replacable hanger, SDS shock damping system
Fork
DT Swiss XRM 100, Air spring, Tapered Steerer, single shot, rebound adjustable, remote Lockout, 100mm travel
Headset
Ritchey Pro Tapered 1.5“ - 1 1/8“, semi integrated
50 / 61mm
Derailleur (Rear)
Sram XX, carbon long cage, 20Speed
Derailleur (Front)
Sram XX, High Mount bottom pull 38.2mm
Shifters
Sram XX Trigger, multi adjustable, with carbon cap, with matchmaker clamp Ti
Brake Levers
Avid XX World Cup Carbon
Brakes
Avid XX World Cup, 180/F and 160/R mm HSX CL Rotor
Crankset
Sram XX, BB30, Carbon crankarm, QF 156,
39Ax26A T
BB-Set
Sram XX, PF30 int., shell 46x73mm
Handlebar
Ritchey Carbon WCS, Flat, 9° bend, 680 mm,
Scott lockon grips
H'stem
Ritchey WCS C-260, Oversize 31.8mm, 1 1/8“,
6° angle
Pedals
nil
Seatpost
Ritchey WCS Carbon, 34.9mm, Scott custom SDS carbon layup
Seat
Ritchey Streem V2 WCS, Titanium
Hub (Front)
DT Swiss XR - RS, CL, RWS QR
Hub (Rear)
DT Swiss XR - RS, CL, RWS QR
Chain
Sram PC 1071
Cassette
Sram XX, 11-36 T
Spokes
DT Swiss Super Comp
Rims
DT Swiss XR-RS, 24 H, Tubeless ready
Tires
Schwalbe Rocket Ron EVO, 26 x 2.1, 127EPI Kevlar Bead, Tubeless ready, Pace star compound
Weight
8.70 kg / 19.16 lbs
